Photoset #516 - Wood-Burning Furnace / 5' x 8' Wood-Burning Furnace

Wood Furnace Front Door / The door is about 3.5' high and 5' wide
Photo #4916
Wood Furnace Front Door / The door is about 3.5' high and 5' wide
Wood Furnace Temperature Gauge and Control Unit / Located on the front--this is the brain of the furnace
Photo #4917
Wood Furnace Temperature Gauge and Control Unit / Located on the front--this is the brain of the furnace
Wood Furnace Fire Box / This firebox is about 5' wide and about 8' deep
Photo #4918
Wood Furnace Fire Box / This firebox is about 5' wide and about 8' deep
Wood Furnace Front Door and Fans / The two fans provide air to the fire, when needed
Photo #4919
Wood Furnace Front Door and Fans / The two fans provide air to the fire, when needed
Wood Furnace Back and Chimney Base / This is where the chimney is to be connected
Photo #4920
Wood Furnace Back and Chimney Base / This is where the chimney is to be connected
Wood Furnace Chimney Connection / This is where the chimney attaches--on the back
Photo #4921
Wood Furnace Chimney Connection / This is where the chimney attaches--on the back
Wood Furnace Side and Forklift Slots / A forklift can handle the furnace from the side through the slots
Photo #4922
Wood Furnace Side and Forklift Slots / A forklift can handle the furnace from the side through the slots
